FREEDOM X 1200 & 1200 PRO

Robust. Durable. Flexible.

Its rugged, industrial design ensures optimum performance in all conditions. Quick connect terminals at AC input & output and pre-wired pigtails cables enable fast and easy installation on the assembly line. Conformal-coated circuit boards and heavy duty metal casing make the FREEDOM X 1200 ideal for mobile applications. It also features true sine wave output, 2x continuous power surge rating, built-in transfer switch and low battery voltage shutdown among other features. The FREEDOM X 1200 Pro has built-in communication card for integration with third-party monitoring and control display panels through RV-C connectivity.

Certifications

  • H.A.L.T
  • ETL listed to CSA Standard C22.2 No. 107.1
  • FCC Part 15, Class B
  • UL458* for marine supplement compliance drip shield in specific mounting orientations when required

Applications

  • Recreational Vehicles
  • Heavy Duty Truck
  • Work Truck

Available in

  • FREEDOM X 1200
    1200 W
    PN: 806-1212
  • FREEDOM X 1200 PRO
    1200 W
    PN: 806-1212-05

Cross-Reference Matrix: Magnum Dimensions to Xantrex

MAGNUM DIMENSIONS MODEL
POWER OUTPUT (CONTINUOUS)
XANTREX FREEDOM X
POWER OUTPUT (CONTINUOUS)
XANTREX PART#
Magnum MM1212
1200W
Freedom X 1200
1200W
806-1212
Magnum MM1212
1200W
Freedom X 1200 Pro
1200W
806-1212-05

Pair with FREEDOM X Combox for RV-C or NMEA2000 connectivity

The FREEDOM X Combox connects the FREEDOM X and XC families of inverter/chargers to an RV-C or NMEA2000 bus to support seamless integration with third party monitoring and control systems.

Back-up Capability with Fast Transfer Time

Incase of a blowout it automatically becomes a power source that supplies utility grade AC power to your loads when installed with DC battery.

Minimum Battery Drain

Built-in protection features safeguard your batteries like the low battery voltage alarm and shutdown and protect equipment such as a configurable AC transfer speed.

Overload and Over Temperature Alarm and Shutdown

What Can Be Powered

FREEDOM X 1200

  • Laptop

  • TV

  • DVD-player

  • Refrigerator

FREEDOM X 1200 PRO

  • Laptop

  • TV

  • Blender

  • Fridge

  • Microwave

  • Iron

  • Coffee Maker

Dimensions

FREEDOM X 1200 & FREEDOM X 1200 PRO

Electrical Specifications

FREEDOM X 1200
FREEDOM X 1200 PRO
Output Power (continuous)
1200 W
1200 W
Surge Rating
2400 W
2400 W
Output Voltage Range
110–125 Vac
110–125 Vac
Output Frequency Regulation (user configurable)
50/60 Hz
50/60 Hz
Output Wave Form
True Sine Wave
True Sine Wave
Efficiency (full load)
> 86%
> 86%
Peak Efficiency
> 91%
> 91%
No-load Input Power (producing output voltage)
< 10 W
< 10 W
Off Mode Current Draw (display off)
< 4 mA
< 4 mA
AC Input Operating Voltage Range
95–130 Vac
95–130 Vac
AC Transfer Relay
30 A
30 A
DC Input Operating Voltage Range
10.5–16.5 Vdc
10.5–16.5 Vdc
Transfer Time
10–20 ms
10–20 ms
Battery Voltage (nominal)
12 Vdc
12 Vdc
Low Battery Cut-out
Adjustable from 10.5–12.1 Vdc
Adjustable from 10.5–12.1 Vdc
AC Receptables
15 A breaker supplied. Optional customer supplied GFCI
N/A

General Specifications

FREEDOM X 1200
FREEDOM X 1200 Pro
Operating Temperature Range
-4–122°F (-20–50°C)
-4–122°F (-20–50°C)
Storage Temperature Range
-40–158°F (-40–70°C)
-40–158°F (-40–70°C)
Operating Humidity Range
5–95%, non-condensing
5–95%, non-condensing
Part Number
806-1212
806-1212-05
Dimensions (L x W x H)
14.8 x 10.4 x 3.5“ (376 x 263 x 91 mm)
14.8 x 10.4 x 3.5“ (376 x 263 x 91 mm)
Net Weight
10.4 lb (4.7 kg)
10.4 lb (4.7 kg)

Regulatory Approval

*When used with drip shield, part #808-1050
FREEDOM X 1200 and 1200 PRO
ETL
ETL listed to CSA Standard C22.2 No. 107.1, UL458* with marine supplement
FCC
CFR 47, FCC, PART 15, Subpart B, Class B and CAN ICES-3 (B) / NMB-3 (B)

Models

Part number
Input voltage
AC output
FREEDOM X 1200
806-1212
12 V
Hardwire (Optional GFCI)
FREEDOM X 1200 Pro
806-1212-05
12 V
Hardwire (Optional GFCI)

Accessories

*FREEDOM X 1200 Pro only
Part number
FREEDOM X Combox
808-0822
Drip Shield
808-1050
Communications and Control (20 pin)*
808-0820
