TRUECharge3 Remote Panel
This full-function remote allows you to monitor and control battery charger performance from a remote location, including features not accessible from the TRUECharge3’s onboard display.
Learn More
Advanced Remote for Monitoring and Full Control of Battery Charger Performance
This full-function remote allows you to monitor and control battery charger performance from a remote location, including features not accessible from the charger’s onboard display. The Remote Panel reads like a fuel gauge and displays critical information on charging of battery banks. It is very easy to install, read and operate, connecting with the battery charger through the included telephone cable. The TRUECharge3 Remote Panel is designed for use with TRUECharge3 Battery Chargers.
Applications
-
Recreational Vehicle
-
Heavy Duty Vehicles
-
Work Truck Vehicles
-
Custom Solutions
-
Marine
Compatible with:
-
TRUEcharge3 12 V20 / 40 / 60 A804-1220-10, 804-1240-10, 804-1260-10
-
TRUEcharge3 24 V10 / 20 / 30 A804-2410-10, 804-2420-10, 804-2430-10
Technical Specifications
Frequently Asked Questions
What can the TRUEcharge3 remote panel do?
The TRUEcharge3 remote panel lets you turn the charger output on/off, view the battery’s state of charge (SOC), and check the charge current. It also displays fault information, adjusts battery temperature settings (cold, warm, hot), and configures the maximum output current from 20% to 100%. It supports parallel charging and activates Quiet Mode for silent operation.
Can the TRUEcharge2 remote panel be used with the TRUEcharge3 charger?
No, the remote panel for TRUEcharge2 is not compatible with the TRUEcharge3 charger. You will need the dedicated TRUEcharge3 remote panel for full functionality with this model.
Does the TRUEcharge3 remote panel have the same size and mounting requirements as the previous model’s remote?
Yes, the TRUEcharge3 remote panel maintains the same form factor and mounting dimensions as the previous model’s remote, making installation easy to integrate into your existing setup.
Can the TRUEcharge3 remote panel change the battery chemistry selection on the charger?
No, battery chemistry selection needs to be set directly on the TRUEcharge3 charger. However, the remote panel provides convenient monitoring of battery status, charging progress, and other critical data.
Does the TRUEcharge3 remote panel allow for changing the charging mode between 2-stage and 3-stage?
No, the charging mode (2-stage or 3-stage) must be selected directly on the charger. The remote panel offers additional control features, such as adjusting maximum output and activating Quiet Mode.
Is the TRUEcharge3 remote panel compliant with FCC regulations?
Yes, the remote panel for the TRUEcharge3 charger is FCC Class B compliant, ensuring safe and reliable operation for marine and mobile environments.
